5-Port 1G Ethernet L2 Unmanaged PoE+ Switch, 4x PoE+ Ports @60W, Metal, Fanless, Desktop/Wall-Mount by FS
Overview
The BG-FS5P60 5-port Gigabit Ethernet Multi-Mode Unmanaged PoE+ Switch provides a seamless network connection, which integrates 1000Mbps Ethernet and 10/100Mbps Ethernet network capabilities. There are 4 Power Sourcing Equipment (PSE) on the switch, which can give power to IEEE802.3af/at Compliant Powered Devices(PD). And the switch also can be switched to a Normal VLAN mode and Monitoring VLAN mode manually. With high integration level, exquisite, easy to operate and portable features, the switch is suitable for the household and office network environment with small or middle scale. It is an ideal choice to promote the performance of the department and working group, can provide a high-performance network applicable solution in simple, economical and standard ways.
Features
- Plug and Play, No Configuration Needed
- 4 PoE+ Ports with 60W Total Power Budget
- Durable Metal Casing, Desktop or Wallmount Options
- 5x 10/100/1000Mbps Auto-Negotiation RJ45 Ports
- Support Port Auto MDI/MDIX
- Fanless and Silent Operation
- Energy Efficient Design Compliant with IEEE 802.3az
Tech Specifications
| Ports | 5x 10/100/1000BASE-T RJ45 |
| MAC Address | 2K |
| Switching Capacity | 10 Gbps |
| Jumbo Frame | 9,000 |
| Forwarding Rate | 7.44 Mpps |
| Transfer Method | Store-and-Forward |
| Packet Buffer | 0.19MB |
| Standards and Protocols | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az |
| Power Supply | DC 51V, 1.25A (External Power Supply) |
| Max. Power Budget | 60W |
| PoE Standard | IEEE 802.3af/at |
| Max. Power Consumption | PoE on 66.1W (220V, 50Hz) |
| Product Material | Metal |
| Mounting Methods | Desktop or Wall-mount |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Storage Temperature | -40°F to 158°F (-40°C to 70°C) |
| Dimensions (HxWxD) | 1.10"x 6.38"x4.02" (28x162x102mm) |
