8X8 4K 60Hz 18Gbps HDMI and Audio Matrix Switcher with Downscaling/AOC Support

SKU: BG-UHD-88M18G
MSRP: Original price was: $2,299.00.Current price is: $999.00.
Status: Limited Stock
Discontinued
Configure the Perfect Solution
Get Started
Overview

Overview

The BG-UHD-88M18G is a professional HDMI2.0 Matrix Switcher with Audio Matrix. It includes eight HDMI inputs and eight HDMI outputs with down-scaling.  This unit is designed for switching HDMI2.0 and HDCP2.3 compliant signals. It also features SPDIF and analog audio outputs for audio matrix functionality. Additionally, it features comprehensive EDID management and advanced HDCP handing to ensure maximum compatibility with a wide range of video sources. The matrix switcher not only supports bi-directional IR, RS232 extension but also has IR, RS232, and TCP/IP control options.

Features

  • 8x8 HDMI 2.0 Matrix Switcher
  • Individual volume adjustment on each L+R output
  • HDMI Output support up to 5V500mA for AOC cable
  • Supports 4K/60 4:4:4, HDR, HDCP2.3 compliant
  • Supports 4K to 1080p down-scaling up to 4 outputs
  • Controllable by front panel, IR, RS232 and TCP/IP
  • Audio Matrix, audio out can be de-embedded from arbitrary input or output
  • HDMI out provides 2.5W to power Active Optical Cable (AOC)
