Home / Products / Capture Cards / Converters / Streaming/Capture Cards

Streaming/Capture Cards

Filter BY Parameters
1080P
4K
IP Control
TAA
BG-CAP-HA
USB 3.0 1080P FHD Powered HDMI Capture Card
SKU: BG-CAP-HA
$49.00
TAA Compliant
BG-CHA
USB 3.1 1080P FHD HDMI Video Capture Card with Scaler and Audio
SKU: BG-CHA
$199.00
TAA Compliant
BG-CSA
USB 3.1 1080P FHD 3G-SDI Capture Card with Scaler and Audio
SKU: BG-CSA
$199.00
TAA Compliant
BG-4KCH
USB-C 4K UHD HDMI Video Capture Card with Scaler
SKU: BG-4KCH
$249.00
TAA Compliant
BG-4KCHA
USB-C 4K60 Video Capture Card with Scaler, HDMI 2.0 loop out, Audio & HDR10 to SDR Conversion
SKU: BG-4KCHA
$349.00
TAA Compliant
BG-4K120CHA
USB-C 4K120 Video Capture Card with Scaler, HDMI 2.1 Loop out, Audio & HDR10 to SDR Conversion
SKU: BG-4K120CHA
$479.00
TAA Compliant
BG-12GCSA
USB-C 12G-SDI Video Capture Card with Scaler, HDMI 2.0/12G-SDI loop out, Audio
SKU: BG-12GCSA
$699.00
Configure the Perfect Solution
Get Started

Comparison Table

SKU Interfaces 1080P 4K Refresh Rate OS Support IP Control TAA Audio Embedding
BG-CAP-HA HDMI in|HDMI out|USB out|Stereo audio in|Stereo audio out YES × 60Hz at 1080P via USB Windows 7 /8.1 /10/11, Mac and Linux OS × × HDMI Embedded Audio & Stereo audio Input
BG-CHA HDMI in|HDMI out|USB out|Stereo audio in YES × 60Hz at 1080P via USB Windows 7/ 8/10/11 Mac OS X 10.9 or above, Linux × YES HDMI Embedded Audio & Stereo audio Input
BG-CSA SDI in|SDI loopout|USB out|Stereo audio in YES × 60Hz at 1080P via USB Windows 7/ 8/10/11 Mac OS X 10.9 or above, Linux × YES SDI Embedded Audio & Stereo audio Input
BG-4KCH HDMI in|USB-C out YES YES 30Hz at 4K via USB-C Windows 7 /8.1 /10/11, Mac and Linux OS × YES HDMI Embedded Audio & Stereo audio Input
BG-4KCHA HDMI in|HDMI out|USB-C out|Stereo audio in|Stereo audio out YES YES 120Hz at 1080P via USB-C Windows 7 /8.1 /10/11, Mac and Linux OS × YES HDMI Embedded Audio & Stereo audio Input
BG-4K120CHA HDMI in|HDMI out|USB-C out|Stereo audio in|Stereo audio out|S/PDIF out YES YES 120Hz at 1080P via USB-C Windows 7 /8.1 /10/11, Mac and Linux OS × YES HDMI Embedded Audio & Stereo audio Input
BG-12GCSA SDI in|HDMI out|SDI loopout|USB-C out|Stereo audio in|Stereo audio out|Toslink out YES YES 120Hz at 1080P via USB Windows 7 /8.1 /10/11, Mac and Linux OS × YES SDI Embedded Audio & Stereo audio Input

    What Does a Capture Card Do?

    A capture device or capture card is a device that enables you to stream or record your video and audio from another source. For example, if you need to stream your gameplay video from your PS5, a capture device will enable you to convert the HDMI signal from the PS5 to USB, that way it can be plugged into your laptop. BZBGEAR capture devices are also compatible with popular streaming software tools, allowing you to take full control of your content.

    Plug and Play

    BZBGEAR capture devices are incredibly easy to use. Hook up your computer and input source and start creating. No setup, no software, no hassle. BZBGEAR has some of the best capture cards for streaming!

    Professional Grade Capture

    There is no easier way to stream your content online. BZBGEAR capture devices are compatible with OBS Studio, Streamlabs OBS, vMix, XSplit, and most other software tools straight out of the box.

    Stream Without a Computer

    Stream directly to your video platform of choice with the BG-HAVS or BG-SAVS. Connect a source to the input, connect an Ethernet cable, follow a few setup steps in the web interface, and you’ll be streaming in no time!

    SDI OR HDMI

    BZBGEAR offers a full line of streaming encoders and capture devices supporting both SDI and HDMI connections. Whether you’re a gamer, a producer, or live streaming an event with professional video equipment, we have the gear you need.

    Features

    • SDI | 3G-SDI
      3G SDI
      Resolutions up to 1080P@60fps
    • Standards Compliance
      HDMI
      Resolutions up to 1080P@60fps
    • SRT
      SRT
      Secure Reliable Transport supported on streaming encoders
    • SMART COMPRESSION
      RTMP
      Stream directly to platforms like YouTube, Facebook, Twitch, and more
    • USB 3.0 | USB 2.0 | USB HOT PLUG
      USB 3.0
      Compatible with most Windows and Mac computers
    • AUDIO DE-EMBEDDING
      AUDIO EMBEDDING
      Add audio from an external source

    The BZBGEAR Difference

    BZBGEAR offers the industry’s best warranty for all products, ensuring unparalleled protection for our clients. Beyond the initial sale, our commitment to service and support extends far into the future. With BZBGEAR, clients can confidently specify, purchase, and install, knowing they have unmatched coverage even in the rare event it’s needed.
