Home / Products / Signal Extenders / HDMI Extenders Over Category Cable

HDMI Extenders Over Category Cable

Filter BY Parameters
HDBaseT
BZB-EXH-50
4K/UHD HDR HDMI Extender (TX/RX) Kit Over Single Cat6/7 up to 165ft with IR and HDMI Loop Out
SKU: BZB-EXH-50
$99.00
BG-EXH-70C
4K UHD HDMI Extender with Bi-directional IR and Zero Latency up to 230ft
SKU: BG-EXH-70C
$109.00
BG-EXH-50C
4K UHD HDMI Extender with Bi-directional IR over a Single Cat5e/6/7 up to 165ft
SKU: BG-EXH-50C
$229.00
BG-EXH-70C3
4K UHD HDMI Extender with Bi-directional IR/PoC/ARC and Audio De-embedding up to 230ft
SKU: BG-EXH-70C3
$249.00
BG-EXH-150C
4K UHD HDMI HDBaseT Long Range Extender with Bi-directional IR RS-232 and CEC up to 490ft
SKU: BG-EXH-150C
$349.00
BG-EXH-70C4
4K UHD HDMI HDBaseT Extender with IR/ARC/PoC/RS-232 and Audio Embedding/De-embedding up to 230ft
SKU: BG-EXH-70C4
$449.00
BG-EXH-100C5
4K UHD HDMI HDBaseT Extender with IR/ARC/PoC/RS-232/Ethernet and Audio Embedding/De-embedding up to 330ft
SKU: BG-EXH-100C5
$699.00
NEW
BG-EXH-8KC6
8K 60fps (4K@120) HDMI Extender with IR/eARC/ARC/PoC/RS-232/Ethernet/USB and Audio Embedding/De-embedding up to 330ft
SKU: BG-EXH-8KC6
$999.00
BG-EXH-100C6
4K UHD HDMI/HDBaseT 3.0 Extender with IR/eARC/ARC/PoC/RS-232/Ethernet/USB and Audio Embedding/De-embedding up to 330ft
SKU: BG-EXH-100C6
$799.00
Configure the Perfect Solution
Get Started

    Comparison Table

    SKU Transmission Distance Max Resolution Audio Formats Video Bandwidth HDBaseT HDMI Compliance HDCP Compliance
    BZB-EXH-50 Up to 165ft (50m) over Cat6/6a/7 4K2K@60Hz RGB/YCBCR 4:4:4 LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DSD-HD Master Audio, DSD 18Gbps × HDMI 2.0 HDCP 1.4|HDCP 2.2
    BG-EXH-70C Up to 230ft (70m) over Cat6/6a/7 4K@60Hz 4:4:4 LPCM/DTS-HD/DTS-Audio/Dolby Digital 5.1CH/Dolby TrueHD 7.1CH 18Gbps × HDMI 2.0 HDCP 1.4|HDCP 2.2
    BG-EXH-50C Up to 165ft (50m) over Cat6/6a/7 4K@60Hz 4:4:4 LPCM 2.0/2.1/5.1/6.1/7.1, Dolby Digital, Dolby TrueHD, Dolby Digital Plus(DD+), DTS-ES, DTS HD Master, DTS HD-HRA, DTS-X 18Gbps × HDMI 2.0 HDCP 1.4|HDCP 2.2
    BG-EXH-70C3 Up to 230ft (70m) over Cat6/6a 4K2K@60Hz RGB/YCBCR 4:4:4 HDMI: LPCM 7.1CH, Dolby True HD, DTS-HD Master Optical: Dolby 5.1, DTS 5.1, PCM 2.0 18Gbps × HDMI 2.0b HDCP 1.4|HDCP 2.2
    BG-EXH-150C Up to 492ft (150m) over Cat6 4K2K@50/60Hz 4:4:4 LPCM 2.0/2.1/5.1/6.1/7.1, Dolby Digital, Dolby TrueHD, Dolby Digital Plus (DD+), DTS-ES, DTS HD Master, DTS HD-HRA, DTS-X 18Gbps YES HDMI 2.0 HDCP 1.4|HDCP 2.2
    BG-EXH-70C4 Up to 230ft (70m) over Cat6 4K2K@60Hz RGB/YCBCR 4:4:4 HDMI: LPCM 7.1CH, Dolby True HD, and DTS-HD Master Optical: Dolby 5.1, DTS 5.1, PCM 2.0 18Gbps YES HDMI 2.0b HDCP 1.4|HDCP 2.2
    BG-EXH-100C5 Up to 328ft (100m) over Cat6 4K@60Hz 4:4:4 HDMI: LPCM 7.1CH, Dolby True HD, and DTS-HD Master Optical: Dolby 5.1, DTS 5.1, PCM 2.0 18Gbps YES HDMI 2.0b HDCP 1.4|HDCP 2.2
    BG-EXH-100C6 Up to 328ft (100m) over Cat6 4K@60Hz 4:4:4 LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD, Master Audio, DSD 18Gbps YES HDMI 2.0b HDCP 1.4|HDCP 2.2

      What is an HDMI Extender?

      HDMI is the modern standard for high-definition audio/video transmission. The convenience of a single A/V connector is, however, offset by a distance limitation. Beyond 50 feet HDMI becomes unreliable and can result in intermittent connections, reduced resolution, or sometimes no connection at all. This is where HDMI extenders step in. The HDMI extender over cat6 can reach up to 100 meters / 328 ft. A cat6 cable is also capable of carrying the data from the HDMI cable over a longer distance without interference. That is 6 times the distance of an HDMI cable!

      To HDBaseT or not to HDBaseT?

      HDBaseT is the industry leading standard for HDMI transmission over category cable. With the purchase of an HDBaseT extender, users are guaranteed top performance and reliability. The HDBaseT standard supports audio, video, power, control and a network connection over a cat6 cable. This standard also supports 100 watts of power over cat6, which is 100 watts over 100 meters / 328 feet. A non-HDBaseT extender can offer significant savings but may have range or feature limitations by comparison.



      Easy Installation

      HDMI Extenders can greatly reduce the labor involved in the installation process. In addition to the distance limitation of HDMI cables; they can also be expensive, bulky, and fragile. It’s not uncommon for HDMI cables to be damaged beyond repair during installation. Category cables are smaller and more durable, making them better suited for custom installation.
      hdmiext2

      FUTURE PROOF

      HDMI Extenders over category cable are a great choice for future-proofing your system. Unlike a physical HDMI cable, when an extender requires replacement or upgrade there is no need to install more wiring. Simply unplug the extender and replace it while using the existing category cable. Overall, BZBGEAR has one of the best HDMI extender options available.

      Features

      • Long-Range | LONG RANGE KVM | LONG RANGE USB | EXTREME RANGE | BUFFERED AND RE-CLOCKED OUTPUTS | ANALOG STEREO RANGE | EXTENDED RANGE
        LONG-RANGE
        Transmit HDMI signals at distances up to 150 meters / 492 feet
      • Full HD and 4K Options
        4K UHD
        Resolutions up to 4K@60fps supported
      • High-Speed Video
        HDMI
        HDMI 2.0a compliant, HDCP 2.2 compliant
      • TEST PATTERNS | EASY INSTALLATION
        EASY INSTALLATION
        Compact designs and category cables simplify installation
      • AUDIO DE-EMBEDDING
        AUDIO DE-EMBEDDING
        Certain models de-embed audio for connection to an audio system
      • IR ROUTING
        IR PASSTHROUGH
        Extend control signals for IR devices
      • Standards Compliance
        HDMI LOOP OUT
        Connect an additional display at the transmitter
      • Durable Mobility
        3 YEAR WARRANTY
        Parts & Labor covered for 3 years.
